Examples
These full-page examples compose Core and Unit components using Layout. Open one full size or use Show layers to inspect its composition.
Shops and apps
Section titled “Shops and apps”- Shop — a photo-led collection with filters and a shopping bag.
- Planning app — project navigation, searchable items and a visual brief.
- Finance app — account balances, cash flow and transactions.
- Product showcase — a product story, large photographs and a package choice.
These are working local examples with fictional content. Their components, colours, type and spacing come from the current DS1 source; example CSS only arranges the pieces.
Sidebar
Section titled “Sidebar”An app with places to go: navigation stays on the left while the work changes on the right.
Point at any part of the page to see what it is made of.
- Page
ds-page- Unit
ds-sidebar,ds-row,ds-tabs,ds-list
<ds-page layout="sidebar" divided fill>
<ds-sidebar slot="nav" label="Workspace"></ds-sidebar>
<ds-row slot="header" fill>
<ds-text literal strong>Atlas</ds-text>
<ds-button primary><ds-icon type="plus"></ds-icon> New item</ds-button>
</ds-row>
<ds-tabs aria-label="Atlas">
<ds-button role="tab" active aria-selected="true">Items</ds-button>
<ds-button role="tab" aria-selected="false">Activity</ds-button>
<ds-button role="tab" aria-selected="false">Files</ds-button>
</ds-tabs>
<ds-gap unit></ds-gap>
<ds-list>
<ds-row fill><ds-text literal>Write the brief</ds-text><ds-badge icon="check">Done</ds-badge></ds-row>
<ds-row fill><ds-text literal>Sketch the home page</ds-text><ds-badge>In progress</ds-badge></ds-row>
<ds-row fill><ds-text literal>Choose the typeface</ds-text><ds-badge>In progress</ds-badge></ds-row>
<ds-row fill><ds-text literal>Review with the team</ds-text><ds-badge>Next</ds-badge></ds-row>
<ds-row fill><ds-text literal>Publish</ds-text><ds-badge>Next</ds-badge></ds-row>
</ds-list>
</ds-page>const sidebar = document.querySelector('ds-sidebar');
let expanded = true;
let selected = 'atlas';
function render() {
sidebar.items = [
{ id: 'inbox', label: 'Inbox', meta: '4', current: selected === 'inbox' },
{ id: 'projects', label: 'Projects', expanded, meta: '3' },
...(expanded ? [
{ id: 'atlas', label: 'Atlas', depth: 1, current: selected === 'atlas' },
{ id: 'harbor', label: 'Harbor', depth: 1, current: selected === 'harbor' },
{ id: 'meadow', label: 'Meadow', depth: 1, current: selected === 'meadow' },
] : []),
{ id: 'archive', label: 'Archive', current: selected === 'archive' },
];
}
sidebar.addEventListener('sidebar-toggle', event => { expanded = event.detail.expanded; render(); });
sidebar.addEventListener('sidebar-activate', event => { selected = event.detail.id; render(); });
render();List and detail
Section titled “List and detail”Many things of one kind: pick one from the list and read it in full beside it. The list column is 16 squares, wide enough for a name and a date.
<ds-page layout="split" divided fill>
<div slot="nav">
<ds-input aria-label="Search messages" type="search" placeholder="Search"></ds-input>
<ds-gap unit></ds-gap>
<ds-list>
<ds-row fill><ds-row><ds-avatar initial="M" color="#f5aad1"></ds-avatar><ds-text literal strong>Mika</ds-text></ds-row><ds-text literal tone="muted">09:41</ds-text></ds-row>
<ds-row fill><ds-row><ds-avatar initial="J" color="#99ff73"></ds-avatar><ds-text literal>Jonas</ds-text></ds-row><ds-text literal tone="muted">Yesterday</ds-text></ds-row>
<ds-row fill><ds-row><ds-avatar initial="S" color="#fec20d"></ds-avatar><ds-text literal>Sara</ds-text></ds-row><ds-text literal tone="muted">Monday</ds-text></ds-row>
<ds-row fill><ds-row><ds-avatar initial="A" color="#ccccff"></ds-avatar><ds-text literal>Ari</ds-text></ds-row><ds-text literal tone="muted">2 Oct</ds-text></ds-row>
</ds-list>
</div>
<ds-row slot="header" fill>
<ds-text literal strong>New photos from the shoot</ds-text>
<ds-button split actions aria-label="Message" options="reply:Reply,archive:Archive"></ds-button>
</ds-row>
<ds-row>
<ds-avatar-group aria-label="Mika and you">
<ds-avatar initial="M" color="#f5aad1" outlined></ds-avatar>
<ds-avatar initial="Y" color="#99ff73" outlined></ds-avatar>
</ds-avatar-group>
<ds-text literal tone="muted">Mika to you</ds-text>
</ds-row>
<ds-gap unit></ds-gap>
<ds-text literal wrap>The first selection is in the shared folder. I kept the ones with daylight on the table and dropped the dark corners.</ds-text>
<ds-gap unit></ds-gap>
<ds-text literal wrap>Pick your three favourites by Friday and I will send them for retouching.</ds-text>
</ds-page>Inspector
Section titled “Inspector”Making something: pages on the left, the work in the middle, its settings on the right. Below 48 squares of width the settings move under the work.
Point at any part of the page to see what it is made of.
- Page
ds-page- Unit
ds-sidebar,ds-row,ds-form,ds-select
<ds-page layout="inspector" divided fill>
<ds-sidebar slot="nav" label="Pages"></ds-sidebar>
<ds-row slot="header" fill>
<ds-text literal strong>Home page</ds-text>
<ds-row end><ds-button secondary>Preview</ds-button><ds-button primary>Publish</ds-button></ds-row>
</ds-row>
<ds-text literal size="heading" strong>A small reading room</ds-text>
<ds-gap unit></ds-gap>
<ds-text literal wrap>A quiet space starts with a few things: daylight, a place to sit and something worth reading. This page shows what a visitor sees first.</ds-text>
<ds-gap unit></ds-gap>
<ds-text literal wrap>Change the words here and the settings beside them. Nothing is saved in this example.</ds-text>
<ds-form slot="aside">
<ds-text literal strong>Page</ds-text>
<ds-input label="Address" name="slug" value="/reading-room"></ds-input>
<ds-row fill><ds-text literal>Status</ds-text><ds-select><select aria-label="Status"><option>Draft</option><option>Published</option></select></ds-select></ds-row>
<ds-row fill><ds-text literal>Show in menu</ds-text><ds-switch><button type="button" role="switch" aria-label="Show in menu" aria-checked="true"></button></ds-switch></ds-row>
<ds-row fill><ds-text literal>Language</ds-text><ds-cycle type="language" compact></ds-cycle></ds-row>
</ds-form>
</ds-page>const sidebar = document.querySelector('ds-sidebar');
let selected = 'home';
function render() {
sidebar.items = ['Home', 'About', 'Visit', 'Events'].map(label => ({ id: label.toLowerCase(), label, current: selected === label.toLowerCase() }));
}
sidebar.addEventListener('sidebar-activate', event => { selected = event.detail.id; render(); });
render();
document.querySelectorAll('ds-switch button').forEach(button => button.addEventListener('click', () => {
button.setAttribute('aria-checked', String(button.getAttribute('aria-checked') !== 'true'));
}));Column
Section titled “Column”Something read or filled in from top to bottom: settings, an article, a long form. The column is 32 squares wide and sits in the middle, on a whole square.
Point at any part of the page to see what it is made of.
- Page
ds-page- Unit
ds-row,ds-list,ds-select,ds-accordion
<ds-page layout="column" fill>
<div slot="header">
<ds-row><ds-text literal strong>Settings</ds-text></ds-row>
<ds-row><ds-text literal tone="muted">Changes apply to this device until you save them.</ds-text></ds-row>
</div>
<ds-list>
<ds-row fill><ds-text literal>Notifications</ds-text><ds-switch><button type="button" role="switch" aria-label="Notifications" aria-checked="true"></button></ds-switch></ds-row>
<ds-row fill><ds-text literal>Weekly summary</ds-text><ds-switch><button type="button" role="switch" aria-label="Weekly summary" aria-checked="false"></button></ds-switch></ds-row>
<ds-row fill><ds-text literal>Theme</ds-text><ds-cycle type="theme"></ds-cycle></ds-row>
<ds-row fill><ds-text literal>Language</ds-text><ds-cycle type="language" compact></ds-cycle></ds-row>
<ds-row fill><ds-text literal>Week starts on</ds-text><ds-select><select aria-label="Week starts on"><option>Monday</option><option>Sunday</option></select></ds-select></ds-row>
</ds-list>
<ds-gap unit></ds-gap>
<ds-accordion summary="Delete your account">
<div slot="details"><ds-text literal wrap>Your items stay on this device for 30 days, then they are removed.</ds-text></div>
</ds-accordion>
<ds-row slot="footer" end>
<ds-button secondary>Cancel</ds-button>
<ds-button primary>Save changes</ds-button>
</ds-row>
</ds-page>document.querySelectorAll('ds-switch button').forEach(button => button.addEventListener('click', () => {
button.setAttribute('aria-checked', String(button.getAttribute('aria-checked') !== 'true'));
}));Centred
Section titled “Centred”One task and nothing else on the screen: signing in, confirming, a single question. The column is 16 squares and sits in the middle of the height too, on a whole square.
<ds-page layout="centered" fill>
<ds-row slot="header"><ds-text literal strong>Sign in</ds-text></ds-row>
<ds-form>
<ds-input label="Email" type="email" name="email" autocomplete="email" placeholder="you@example.com" required></ds-input>
<ds-button primary>Send me a code</ds-button>
</ds-form>
<ds-text literal slot="footer" wrap tone="muted">We email you a six-digit code. This example sends nothing.</ds-text>
</ds-page>const form = document.querySelector('ds-form');
const note = document.querySelector('ds-text[slot="footer"]');
form.querySelector('ds-button').addEventListener('click', () => form.submit());
form.addEventListener('form-submit', event => {
note.text = 'A code would go to ' + event.detail.data.email + '. Nothing was sent.';
});
form.addEventListener('form-invalid', () => { note.text = 'Enter your email address to get a code.'; });An overview of many numbers at once. Each tile is 12 squares wide and the row fills with as many as fit; data-tile="wide" takes two, data-tile="full" the whole row.
<ds-page layout="tiles" fill>
<ds-row slot="header" fill>
<ds-text literal strong>This week</ds-text>
<ds-button split aria-label="Period" options="day:Day,week:Week,month:Month" value="week"></ds-button>
</ds-row>
<section data-tile="wide">
<ds-row fill><ds-text literal>Visitors</ds-text><ds-text literal strong>2,480</ds-text></ds-row>
<ds-chart kind="area" rows="6" aria-label="Visitors over two weeks, rising from 12 to 24 a day"></ds-chart>
</section>
<section>
<ds-row fill><ds-text literal>Sign-ups</ds-text><ds-text literal strong>124</ds-text></ds-row>
<ds-spark aria-label="Sign-ups rising over two weeks"></ds-spark>
<ds-gap unit></ds-gap>
<ds-row fill><ds-text literal>Returning</ds-text><ds-text literal strong>65%</ds-text></ds-row>
<ds-ratio aria-label="65 percent returning, 35 percent new"></ds-ratio>
</section>
<section>
<ds-row fill><ds-text literal>By day</ds-text><ds-badge>Sample</ds-badge></ds-row>
<ds-bars rows="5" aria-label="Monday 12, Tuesday 20, Wednesday 15, Thursday 18, Friday 24"></ds-bars>
</section>
<section data-tile="wide">
<ds-row><ds-text literal>Projects</ds-text></ds-row>
<ds-table></ds-table>
</section>
</ds-page>const values = [12, 15, 14, 18, 16, 21, 19, 17, 22, 20, 24, 23, 26, 24];
document.querySelectorAll('ds-chart').forEach(chart => {
Object.assign(chart, { data: values.map((value, index) => ({ time: index * 86400, value })), format: value => String(Math.round(value)) });
});
document.querySelectorAll('ds-spark').forEach(spark => { spark.values = values; });
const bars = document.querySelector('ds-bars');
bars.items = [
{ label: 'Mon', value: 12 }, { label: 'Tue', value: 20, tone: 'up' }, { label: 'Wed', value: 15 },
{ label: 'Thu', value: 18 }, { label: 'Fri', value: 24, tone: 'up' },
];
document.querySelector('ds-ratio').value = 0.65;
document.querySelector('ds-table').data = [
{ product: 'Atlas', users: 120, retention: '92%' },
{ product: 'Harbor', users: 80, retention: '88%' },
{ product: 'Meadow', users: 64, retention: '79%' },
];HTML examples
Section titled “HTML examples”Each HTML example is a complete HTML document. Open it to try the page, or download the file and edit it in any text editor. No framework, package install or build step is needed.
The files load the Design system 1 stylesheet and bundled Lit module from this site, then use ds-* elements alongside semantic HTML. Fonts load with the stylesheet. These are online dependencies.
An article
A reading page composed with Page and semantic prose. It loads the same Lit component library as every other example.
A form with local feedback
Lit fields, a multiline input and buttons in a native form. Validation remains native; submission only shows a local message and sends nothing.
A small report
A Page and Table with sample attendance data. The script waits for Table registration before assigning its columns and rows.
An expandable reference
Page and Accordion components, loaded directly in HTML. Open each section with the pointer or keyboard.
What you download
Section titled “What you download”One authored HTML file, including any example-specific script. The Lit module registers the components. The form shows local feedback and prevents submission; it has no backend.
To work offline, serve a local copy of the library bundle, its chunks, CSS and fonts, then update the URLs in your HTML.
For more components, see the component examples, or start with Use with HTML.
